Dry-Type Air-Core Reactor

Short Description:

Classification and uses

The connection of reactors is divided into series connection and parallel connection. Series connected reactors usually function as current limiters, while parallel connected reactors are often used for reactive power compensation.

Series connected reactors play a role in suppressing impulse current when the capacitor circuit installed in the capacitor circuit is put into operation, and also form a harmonic circuit together with the capacitor bank to filter specific harmonics.

Parallel connected reactors are connected to the primary coil of transformer in ultra-high distance transmission system. It is used to compensate the capacitive charging current of the line, limit the system voltage rise and operating overvoltage, thus reducing the insulation level of the system and ensuring reliable operation of the line.

Send email to us Download as PDF

Product Detail

Product Tags

Dry-Type Air-Core Series Reactor

Conditions of use

1. Place of use: outdoor or indoor

2. Service environment temperature: -5℃ ~+40℃

3. ASL: 1000m (please specify at ordering if exceeding 1000m)

4. The installation place shall have no harmful gas, steam and conductive or explosive dust

Product parameter

Types of meaning

15216241063325910

Rated voltage and the related technical parameters

Rated power system (kV)	Parallel capacitor group		Series reactor rated voltage (kV)
	The rated voltage (kV)	Each phase serial number	Rated reactance rate (%)
	The rated voltage (kV)	Each phase serial number	4.8	6	12	13
6	6.6/√3	1	0.183	0.229
6	7.2/√ 3	1			0.499	0.54
10	11/√ 3	1	0.305	0.381
10	12/√ 3	1			0.831	0.901
	11	2	1.056	1.32
	12	2			2.88	3.12
63	20	2	1.92	2.4
63	22	2			5.28	5.72

Dry-Type Air-Core Reactor manufacturer

Zhejiang Pengbian Electric Co., Ltd. is located in China’s electrical capital, is a collection of high-tech at home and abroad in one, the development and production of power transmission equipment key enterprises.

The company has advanced production equipment and exquisite manufacturing technology, specializing in the production of dry type transformer, oil-immersed transformer, special transformer, all kinds of reactor, wind power, photovoltaic transformer substation, substation transformer core, European-style box-type substation, American box transformer substation, high and low voltage complete sets of electrical equipment, power transmission and transformation equipment such as high and low voltage switchgear. Products should be widely in electric power, railway, industrial and mining enterprises, shipping, etc.

Product Features

A multi-tap type reactor with single capacity and multi-capacity set can be provided according to user requirements,which can realize the automatic switching of reactors with different compensation capacities.

Product Usage

In the shunt compensation capacitor device,it is used in series with the shunt capacitor bank to suppress harmonic amplification,reduce system voltage distortion, and limit the closing inrush current when the capacitor bank is switched.
